SYNCHRONIZING ROOM TRAVEL
The Lippert Electric Slideout System room travel (both sides of the room
traveling the same distance) can be adjusted with specially designed
synchronizing bracket mounted on the passive slide tube. The passive
slide tube is the one that is not powered. The active slide tube is the one
that has the cylinder attached. If one side of the room fails to seal adjust
as follows:
1. Loosen bolts (Fig. 9 A) on top of the passive slide
tube (Fig. 9B)
2. Push or pull room (on the passive side) to align with the
active side.
Fig.9
A
B
