2
Rev: 09.04.2013 - Schwintek Bunk Lift OM DRAFT
SYSTEM DESCRIPTION
The Bunk Lift System is designed to raise and lower an unoccupied and unloaded bunk
bed integrated into a dinette/bed setting in a stationary recreational vehicle.
IMPORTANT!!
NOTE: Bed is not to be occupied, loaded or used for cargo storage in any way while
being raised or lowered. The dinette/bed setting is not to be occupied during
raising or lowering the bunk bed.
NOTE: Periodic light lubrication (CRC PowerLube or equivalent) of the gear racks may
be necessary if gear chatter sounds occur due to normal wear.
OPERATION
1. Press and hold the "DOWN" button until the Bunk Lift lowers into the rested
position and hold down the switch for a couple seconds after the bunk has
ceased to move.
2. Press and hold the "UP" button until the Bunk Lift raises up to the ceiling and
continue to hold down the switch for a couple seconds after the bunk has ceased
to move.
