WIRING HARNESS DIAGRAM
RE
D RE
D G
REY
BL
ACK
/WHI
TE
BL
UE G
REEN
YE
LLO
W
BL
ACK
BLACK
BLA
CK/
WH
ITE
GREY
RED
10A
BLUE
& BLACK
3
2
1
BLACK
4
5
1 2 3 4 5 6 7 8
2
Number
1
2
3
4
5
6
7
8
Color
Black
Yellow
Green
Blue
Black/White
Grey
Red
Red
Function
Ground
Switch Extend
Switch Retract
Front Leveling
Trombetta - T1
Trombetta - T2
12V Power
12V Power
KEY - 4-PIN HARNESS - REAR
KEY - 8-PIN HARNESS
KEY - 4-PIN HARNESS - FRONT
KEY - TROMBETTA HARNESS
KEY - DEUTSCH CONNECTORS
KEY - 6-PIN HARNESS
Number
1
2
3
4
Color
Red
Grey
Black/White
Purple
Number
1
2
3
4
Color
Red
Yellow
Green
NO PIN
Number
1
2
3
4
5
Color
Black/White
Black
Black
Grey
Red
Number
1
2
3
4
5
6
Color
Blue & Black-Short
Blue & Black - Long
Purple/White & Black
Orange & Black
Purple & Black
Tan & Black
Number
1
2
3
4
5
6
Color
Red
Grey
Black/White
Orange
Tan
Purple
Function
12V Power
Rear Stab Extend
Rear Stab Retract
Rear Stab Valve
Function
Trombetta - (T1)
Battery Ground - (B-)
Battery Ground - (B-)
Trombetta - (T2)
12V Power - (B+)
Function
Left Front Leveling
Right Front Leveling
Rear Stab-Base
Door Side Slide-Rod
Off-Door Side Slide-Rod
Bedroom Slide-Rod
Function
12V Pwer
Room Extend
Room Retract
Door Side Slide
Bedroom Slide
Off Door Side Slide
Function
12V Power
Switch Extend
Switch Retract
N/A
