Page 6
06
Using the mic
LCT 940
Status indicator ③
■
The microphone is in normal working mode if the status indicator is illuminated in white.
■
The microphone is in key-lock mode if the status indicator is not illuminated.
■
The microphone experiences clipping due to high SPL if the status indicator flashes in red.
■
The microphone is in automatic attenuation mode if the status indicator is illuminated in red.
■
The microphone indicates the clipping history if the status indicator flashes red and white in an alternating sequence.
Stageless Amplification selection ④
■
Turn the rotary knob and select the desired amplification. Clean “FET” and warm “TUBE” amplification is available on the far right
and left position, a mixture of the two in between.
■
The actual amplification mix is indicated by the red illuminated dot or red illuminated “FET” or “TUBE” indication.
Polar pattern selection ⑤
■
The currently active polar pattern is illuminated in white. If an intermedia polar pattern is selected the neighboring
polar pattern are illuminated in red as well.
■
Select up to nine different directivity characteristics by briefly turning the jog-dial to the right or left.
High-pass filter indications ⑥
■
The currently active high-pass filter setting is illuminated in white.
