To install your detachable Keymod Compatible
Picatinny Rail Sections or other Keymod
compatible accessories, please refer to the
following steps.
Hold the Keymod Nut in place (16.1) and
loosen the screw by turning it counter-
clockwise with the included 3/32” Allen
Wrench. Do not fully detach the Keymod
Screw from the Keymod Nut.
NOTE: The Keymod Nut and Screw can
be fully disassembled if needed.
16
Attaching
Picatinny Rail
Sections
17
16.1
Place the rail with the Keymod Nuts onto the
desired slots of the handguard rail, inserting
the nuts through the larger opening of the
Keymod Slots with the protruding feet of the
nuts pointing toward the muzzle of the firearm
(17.1).
Once the Keymod Nuts are in the slots,
carefully slide the Rail Section forward until it
fully seats into and engages the handguard,
with little to no gap between the Rail Section
and the handguard.
(18.1, 18.2, 18.3)
17 18
BARREL BARREL
18
17.1
18.1 18.2 18.3
