LAARS Heating Systems
Contents Pgs -
Familiarizing yourself to the Laars Mascot LX .............1
1. Caring For Your Mascot LX ......................................2
2. Filling, shut Down and Restart ...............................2-3
3. the User Interface and the Digital Display ............4-5
M
ascot
®
LX
FAMILIARIZING YOURSELF TO THE
LAARS Heating Systems
M
ASCOT
LX
Figure 1. Opening the Mascot LX.
The top and bottom panels come off when
pulled forward. This is true for all sizes.
START-UP
INSTRUCTIONS
SECTION 1.
General Information
WARNING
Mascot LX units
must be installed in accordance with the procedures detailed in this manual, or the LAARS Heating
Systems warranty will be voided. The installation must conform to the requirements of the local jurisdiction having
authority, and, in the United States, to the latest edition of the National Fuel Gas Code, ANSI Z223.1/NFPA54. In
Canada, the installation must conform to the latest edition of CSA B149.1 Natural Gas and Propane Gas Installation
Code, and/or local codes. Where required by the authority having jurisdiction, the installation of Mascot LX boilers
must conform to the Standard for Controls and Safety Devices for Automatically Fired Boilers, ANSI/ASME CSD-
1. Any modifi cations to the boiler, its gas controls, or wiring may void the warranty. If fi eld conditions require
modifi cations, consult the factory representative before initiating such modifi cations.
WIRING
DIAGRAM
RATING PLATE
