Fig. 2
Technical data:
Mass: 1650 gr
Effective length : 280 mm ( 11 inch)
Mounting distance: 212 mm
Offset angle: 19.50 degrees
Distance from spindle to
horizontal bearing: 264 mm
Effective mass: 13 g
VTA adjustment: yes
Azimuth adjustment: yes
Bias adjustment: yes
Vertical damping: yes
Horizontal damping: yes
Detachable headshell: yes ( one extra supplied)
Cables: biwiring
Arm mount: Kuzma 212 mm
Optional: single wiring, extra headshells
4
azimuth lock VTA scale - fine horizontal bearing assembly
vertical bearing point azimuth adjustment
bias
