Q

UICK

S

PECS

Options

10

DA-10030-01-010 — 07.20.2000

Compaq AlphaStation XP1000

Step 6

−−−−

Graphics (continued)

• Linux customers should refer to their Linux supplier for graphic adapter support

Maximum # Supported

Windows NT Tru64 UNIX OpenVMS

ELSA GLoria Synergy graphics with 8-MB SGRAM, TrueColor at

1280 x 1024

1/3

1

4

1

5

1

SN-PBXGK-BB

PowerStorm 300 Midrange 3D graphics with 15-MB frame buffer

memory and 16-MB texture memory, TrueColor at 1280 x 1024

2 3

2

4

4

SN-PBXGD-AD

PowerStorm 350 Midrange 3D graphics with 30-MB frame buffer

memory and 32-MB texture memory, TrueColor at 1900 x 1200

2 3

2

4

4

SN-PBXGD-AE

3

(1) Windows NT supports one head for 2D/3D, two or three heads for 2D only; Tru64 UNIX and OpenVMS support one to three heads

for 2D only.

(2) Updates on multi-head support can be located at

http://www1.service.digital.com/open3d

(3) PowerStorm 350 customers that require displaying the highest resolution stereo graphics (1280x1024 @ 120Hz) should consider

the Viewsonic P817 monitor as their monitor solution.

(4) OpenVMS supports up to three PowerStorm 300 adapters and one PowerStorm 350 adapter on the same PCI bus. The TIMA

update kit for multi-head support can be found at

http://www.openvms.compaq.com/openvms/products/mmov

Please note this web site is available in English only.

Step 7

−−−−

Color Monitors

• Country Kit includes two country-specific power cords, one for system and one for monitor
P700 Monitor

17

(16

viewable image size) professional series auto-scanning color monitor, Flat

Definition Trinitron CRT, 0.25 mm aperture grill pitch, VGA to 1280 x 1024 at 75 Hz, TCO 99,

MPR-II, Energy Star, attached 1.8-m video cable; without power cord, Northern hemisphere

3R-VRQP7-24

Same as above, Southern hemisphere

3R-VRQP7-23

P900 Monitor

19

(18

viewable image size) professional series auto-scanning color monitor, Flat

Definition Trinitron CRT, 0.25 mm aperture grill pitch, VGA to 1280 x 1024 at 75 Hz, TCO 99,

MPR-II, Energy Star, attached 1.8-m video cable; without power cord, Northern hemisphere

3R-VRQP9-24

Same as above, Southern hemisphere

3R-VRQP9-23

P1100 Monitor

21

(19.6

viewable image size) auto-scanning color monitor, Trinitron CRT, 0.28

mm aperture grill pitch, VGA to 1600 x 1200 at 85 Hz NI, TCO 99, Energy Star, includes 1.8-m

video cable; without power cord, Northern hemisphere

3R-VRQP1-24

Same as above, Southern hemisphere

3R-VRQP1-23

TFT 18” Panel Monitor

18” viewable image size, TFT diagonal viewable image area; support for a

maximum 1280 x 1024 display resolution at 75 Hz; 160 degree horizontal and vertical viewing

angles; removable base; pixel pitch of 0.28 mm; brightness of 200 nits (typical); LiteSaver that

conserves energy and backlight life

3R-A0852-AA

Step 8

−−−−

Network Options

• Systems include onboard 10/100 Ethernet (Twisted pair) controller

Maximum # Supported

Windows NT Tru64 UNIX OpenVMS

XP1 MAU 10Base5 AUI/Thickwire

1 1 1

SN-PCXAN-DE

XP1 MAU Card 10Base2 ThinWire

1 1 1

SN-PCXAN-DF

PCI-to-10/100 Ethernet NIC 8255x

- 2

2

3X-DE600-AA

PCI Token Ring adapter, must be installed in PCI-1 bus for both Windows

NT and Tru64 UNIX

2 2 2

SN-PBXNP-AC

PCI FDDI adapter, DAS TP-PMD

2 2 2

3X-DEFPA-MC
