G-Shock GX-56 - Manual

Operation Guide 3221
1
MO1006-EA
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
Keep the watch exposed to bright light
The electricity generated by the solar cell of the watch is
stored by a rechargeable battery. Leaving or using the
watch where it is not exposed to light causes the battery
to run down. Make sure the watch is exposed to light as
much as possible.
• When you are not wearing the watch on your wrist,
position the face so it is pointed at a source of bright
light.
• You should try to keep the watch outside of your sleeve
as much as possible. Charging is reduced significantly if
the face is covered only partially.
ll
l l l l l l l l l
Bright Light
Solar cell
All
functions
enabled
LEVEL 1
LEVEL 2
LEVEL 3
LEVEL 4
Charge
Rechargeable battery
Bright Light
Electrical
energy
Solar cell
(Converts light to
electrical power.)
LEVEL 1
LEVEL 2
LEVEL 3
LEVEL 4
Some or all
functions
disabled Dis-
charge
Battery charges in the light. Battery discharges in the dark.
• The watch continues to operate, even when it is not exposed to light. Leaving the
watch in the dark can cause the battery to run down, which will result in some watch
functions to be disabled. If the battery goes dead, you will have to re-configure watch
settings after recharging. To ensure normal watch operation, be sure to keep it
exposed to light as much as possible.
• The actual level at which some functions are disabled depends on the watch model.
• Frequent display illumination can run down the battery quickly and require charging.
The following guidelines give an idea of the charging time required to recover from a
single illumination operation.
Approximately 5 minutes exposure to bright sunlight coming in through a window
Approximately about 8 hours exposure to indoor fluorescent lighting
• Be sure to read “Power Supply” for important information you need to know
when exposing the watch to bright light.
If the display of the watch is blank...
If the display of the watch is blank, it means that the watch’s Power Saving function
has turned off the display to conserve power.
• See “Power Saving Function” for more information.
About This Manual
• Depending on the model of your watch, display text appears either as dark figures
on a light background or light figures on a dark background. All sample displays in
this manual are shown using dark figures on a light background.
• Button operations are indicated using the letters shown in the illustration.
• Each section of this manual provides you with the information you need to perform
operations in each mode. Further details and technical information can be found in
the “Reference” section.
General Guide
• Press C to change from mode to mode.
• In any mode (except when a setting screen is on the display), press B to illuminate
the display.
Timekeeping Mode
Press C.
Countdown Timer Mode Stopwatch Mode
Alarm Mode
▲
▲
World Time Mode
▲
llll ll
llll
▲
▲
Timekeeping
Press the A button to toggle the upper display between
the day of the week and date, and the currently selected
World Time city and time (Dual Time).
Use the Timekeeping Mode to set and view the current
time and date.
Read This Before You Set the Time and Date!
This watch is preset with a number of city codes, each of
which represents the time zone where that city is located.
When setting the time, it is important that you first select
the correct city code for your Home City (the city where
you normally use the watch). If your location is not
included in the preset city codes, select the preset city
code that is in the same time zone as your location.
• Note that all of the times for the World Time Mode city
codes are displayed in accordance with the time and
date settings you configure in the Timekeeping Mode.
Current Time
PM indicator
Hour : Minutes
Seconds
Day of week
Dual Time
A A
Month – Day
▲
▲
lll l l lllll
Dual time City code
To set the time and date
1. In the Timekeeping Mode, hold down A until the city
code starts to flash, which indicates the setting screen.
2. Press D and B to select the city code you want.
• Make sure you select your Home City code before
changing any other setting.
• For full information on city codes, see the “City Code
Table”.
3. Press C to move the flashing in the sequence shown below to select the other
settings.
Seconds
12/24-Hour
Format
Hour Minutes DST
Month Year
City Code
Day Power Saving Illumination
Duration
Button
Operation Tone
lll
lll
ll lll
ll
l l l l
• The following steps explain how to configure timekeeping settings only.
4. When the timekeeping setting you want to change is flashing, press D or B to
change it as described below.
Change the city code
Toggle between Daylight Saving Time
(
ON ) and Standard Time ( OFF ).
Toggle between 12-hour ( ) and 24-
hour ( ) timekeeping
Reset the seconds to
Change the hour and minutes
Press D (east) and B
(west).
Press D.
Press D.
Press D.
Press D (+) and B (–).
Screen: To do this: Do this:
5. Press A to exit the setting screen.
• The day of the week is displayed automatically in accordance with the date (year,
month, and day) settings.
To do this: Do this:
Change the year, month, or day
Toggle the button operation tone between
(on) and (off)
Toggle the illumination duration between
(approximately 1.5 seconds) and
(approximately 3 seconds).
Toggle between Power Saving on ( )
and off ( )
Press D (+) and B (–).
Press D.
Press D.
Press D.
Screen:
/
12-hour and 24-hour timekeeping
• With the 12-hour format, the P (PM) indicator appears to the left of the hour digits for
times in the range of noon to 11:59 p.m. and no indicator appears to the left of the
hour digits for times in the range of midnight to 11:59 a.m.
• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
any indicator.
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To change the Daylight Saving Time (summer time) setting
1. In the Timekeeping Mode, hold down A until the city
code starts to flash, which indicates the setting screen.
2. Press C and the DST setting screen appears.
3. Press D to toggle the DST settings ON and OFF.
DST off (OFF) DST on (ON)
4. When the setting you want is selected, press A to exit
the setting screen.
• The DST indicator appears to indicate that Daylight
Saving Time is turned on.
l l
l ll ll ll
ll
l l l l
ll
l l l l l lll
ll l
DST indicator
