Crimestopper Security Products CS-2002DC - Manual (Page 19)

+ -
+
BLACK(GROUND)
WHITE(WARNING)
RED (+)
BLUE (TRIGGER)
RED
WHITE
BROWN
BLUE/WHITE
WHITE/RED
ORANGE
BLACK/WHITE
BLUE
GRAY
YELLOW
BLACK
VIOLET
GREEN
LED
OVERRIDE/
PROGRAM
BUTTON
BATTERY
(-) LOCK OUTPUT
+12 VOLT FOR RELAYS
(-) UNLOCK OUTPUT
GREEN
BLUE
RED
CS-2002DC
(-) NEG. DOOR
PIN SWITCH
(+) POSITIVE DOOR
PIN SWITCH
FUSE
BOX
IGN.
SW
(-) REMOTE OUTPUT 1
(-) HOOD/TRUNK TRIGGER
(-) DOOR TRIGGER
(+) DOOR TRIGGER
CHASSIS GROUND
(+) SWITCHED IGN "ON"
SIREN
PARKING
NEG. ARMED OUTPUT
(STARTER DISABLE)
OPT.
RELAY
85 86
87 30
87a
85 86
30 87A
85 86
87 30
87a
10A MAX
3A MAX
LIGHTS
FUSE
15A
CUT
START WIRE
IGNITION
"ON & START"
STARTER
(-) REMOTE OUTPUT 2
85 86
87 30
87a
Single Adjust
Shock Sensor
(-) NEG.
PIN SWITCH
(-) DOME LIGHT OUTPUT
+12V POWER
(-) PASSENGER
UNLOCK OUTPUT
ACTIVATES ON
SECOND PRESS
OF UNLOCK BUTTON
+ OR
DOME LIGHT
OUTPUT
BROWN/WHITE
(-) HORN HONK
OPT.
RELAY
CS-2002DC II
Dual Adjust Shock Sensor &
LED/Valet POD included with
Series II Systems only.
