Crimestopper Security Products CS-2002DC User Manual
Introduction, Tech support

CS-2002DC & CS-2002DC Series II
REMOTE CONTROL ALARM SYSTEM
INSTALLATION & OPERATING INSTRUCTIONS
INTRODUCTION
CONGRATULATIONS on your choice of a Gargoyle™ Remote Alarm System by Crimestopper Security
Products Inc. This booklet contains the information necessary for installing, using, and maintaining your alarm
system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the
Tech Support number below.
*IMPORTANT INFORMATION: Primary and Optional Features:
-PRIMARY: These are features that must be connected in order for the system to operate properly; i.e. the
Siren, L.E.D., +12V Power, Ground, Doorpin, Override/Program/Valet Button etc.
-OPTIONAL: These are features to be connected if desired or agreed upon by the installing dealer. These
features may also require additional parts and/or labor fees. Consult with your installer beforehand; i.e. Door
Locks, Flashing Lights, Hood/Trunk trigger, and Auxiliary Remote Outputs etc.
This device complies with FCC Rules part 15. Operation is subject to the following
two conditions: 1) This device may not cause interference, and (2) this device
must accept any interference that may be received, including interference that may
cause undesired operation. The manufacturer is not responsible for any radio or
TV interference caused by unauthorized modification to this equipment. Such
modification could void the user's authority to operate the equipment.
TECH SUPPORT
Mon-Fri 8:00 AM-4:30 PM Pacific Time
(800) 998-6880
REV. D 7/2002 SW: T2, SC, HC, Latest: CH-(Green dot)
Document Outline
- CS-2002DC & CS-2002DC Series II
- REMOTE CONTROL ALARM SYSTEM
- INSTALLATION & OPERATING INSTRUCTIONS
- SIREN: Mount the siren under the hood to an inner fender-well, wheel-well, or other body surface with the open end facing downward. Run the red siren wire through the firewall using a rubber grommet. Ground the black to the body metal near the siren or
- ORANGE WIRE: STARTER KILL / NEGATIVE ARMED OUTPUT (500mA Ground)
- BLUE WIRE: (-) HOOD/TRUNK TRIGGER (Optional)
- GREEN WIRE: (-) DOOR TRIGGER
- VIOLET WIRE: (+) DOOR TRIGGER
- WHITE/RED WIRE: (-) AUX REMOTE OUTPUT 2 (Optional, may require a relay)
- BLACK/WHITE WIRE: (-) DOME LIGHT ILLUMINATION OUTPUT (Optional, may require a relay)
- BROWN/WHITE WIRE: (-) HORN PULSE / CHIRP OUTPUT (Optional, may require a relay)
- BLUE/WHITE WIRE: (-) PASSENGER(S) DOOR UNLOCK OUTPUT (Optional, requires relay)
- 2 PIN PLUG (BLUE): PROGRAM/OVERRIDE PUSH BUTTON
- PROGRAMMABLE OPTIONS
- 4. IGNITION-CONTROLLED LOCKS
- 7. DOUBLE UNLOCK PULSE
- 9. PARKING LIGHTS ON WITH DISARM
- 12. DOOR LOCK/UNLOCK PULSE TIME
- 13. ACTIVE, PASSIVE, or FULL-TIME CARJACK PROTECTION
- 14. CARJACK FEATURES
- IGNITION-CONTROLLED DOORLOCKS
- 2nd AUX. OUTPUT (REMOTE AUX. OUTPUT 2)
- 2 VEHICLE CONTROL
- ACTIVE CARJACK
- PASSIVE CARJACK
- FULL-TIME CARJACK
- Button 1: Arm
