SOLUTION TANK ASSEMBLY
86037910 CEXT7 03/23/07
5-14
REF PART NO.
PRV NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86233140
20041
3
CLAMP, 2.0" WORM GEAR
2
86233150
20042
1
CLAMP, 3/8 HOSE (D-SLOT)
3
86003080
27809
1
COVER, VAC MOTOR
4 86003090 27810 1 COVER,
BELT
5
86235550
31081
1
ELBOW, 3/8 MPT X 3/8 TUBE, PLASTIC
6
86003790
35175
2
GASKET, TANK TO VAC COVER
7
86003920
35231
2
GASKET, VAC COVER
8
86281880
39526
1
HOSE,1/2 CLEAR X 12
9
86240090
39527
1
HOSE, 1.5 BLK VAC X 3.0
10
86004340
39528
REF HOSE ASM, 1.5 BLK VAC X 15.5
11 86001590 40049
1 HOSEBARB,
3/8MPT X 1/2 NYLON
12
86240980
41348
1
HOUSING, VAC MOTOR
13
86026880
53789
1
VAC MOTOR ASM
-
86135320
140687
-
BRUSH SET, 120V VAC
SERVICE
ONLY
14
86006600
70114
2
SCR, #10 X 3/4 PPHST TYPE B
15
86006590
70088
2
SCR, 10-32 X 1/2 PPHMS SS
16 86032240 75257
1 TANK,
CDT
SOLUTION
17
86259060
85037
1
VENT, COOLING AIR SMALL
18
86010650
87018
10
WASHER, #10 X 9/16 OD
19
86007970
73864
1
STRAINER, 3/8 IN. NPT 60 MESH
20
86010630
87013
3
WASHER, 1/4 ID X 5/8 OD SS
21
86006580
70085
3
SCR, 1/4-20 X 1/2 PPHMS SS DL
22
86002370
20035
2
CLAMP, 7/16 DIA NYLON UL
23
86233260
20092
1
CLAMP, 3.5" WORM GEAR
24
86272840
67147
1
RING, 2" DIA SPLIT
25
86256170
73169
1
STRAIN RELIEF, CORD HOOK
26
86003950
35236
1
GASKET, TANK, L-F
27
86003960
35237
1
GASKET, TANK, L-R
28
86003970
35238
1
GASKET, TANK, RH
29
86275690
70525
6
SCR, #10 X 1.0 PPHST TYPE B
30
86003940
35235
1
GASKET, CDT PANEL
31
86026660
75276
1
TANK ASM, SOLUTION
*ITEMS
32
86177090
03-000261
1
CLAMP, CABLE 1/2 ID 1/4BLT
