Page 12 For technical questions, please call 1-800-444-3353. Item 68099
SAFET
y
Op
ERA
TION
M
AINTENANCE
SETU
p
parts List and Diagram
pLEASE READ THE FOLLOWING CAREFULLy LEASE READ THE FOLLOWING CAREFULL LEASE READ THE FOLLOWING CAREFULL
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts List
part Description Description Qty Qty
1 Self-tapping screw Self-tapping screw 4
2 Head module 1
3 Seal ring Seal ring 1
4 Slide bearing Slide bearing 1
5 Anvil 1
6 Retaining ring Retaining ring 1
7 Rubber ring Rubber ring 1
8 Impact plate Impact plate 1
9 Steel ball 1
10 Washer 1
11 Spring Spring 1
12 Steel ball 1
13 Main shaft 2
14 Large gear Large gear 1
15 Washer 1
16 Slide bearing Slide bearing 2
17 Cylinder pin Cylinder pin 1
18 Washer 1
19 Middle gear Middle gear 1
20 Ball bearing Ball bearing 1
21 Washer 1
22 Seal ring Seal ring 1
23 Middle cover 1
24 Seal ring Seal ring 1
part Description Description Qty Qty
25 Bearing (6001Z) Bearing (6001Z) 1
26 Rotor 1
27 Bearing (6072Z) Bearing (6072Z) 1
28 Bushing Bushing 1
29 Washer 1
30 Wind ring Wind ring 1
31 Self-tapping screw Self-tapping screw 1
32 Stator 1
33 Housing Housing 1
34 Label 1
35 Brush holder 1
36 Carbon brush 2
37 Brush cover 1
38 Trigger Trigger 1
39 Switch 1
40 Terminal 6
41 Wire 1
42 Self-tapping screw Self-tapping screw 2
43 Cable plate Cable plate 2
44 Carbon brush wire 2
45 Cable sheath 1
46 Power Cord 1
47 Handle 1
