VTX65 TECHNICAL SPECIFICATIONS:
Output Power Rating
65W RMS @5% THD, 8
Ω
, 120 VAC
Speaker Size and Rating
(1) Custom Design 12”, 8
Ω
Input Impedance
470k
Ω
Total System Gain
Solo Ch
110dB, all controls @10
Rhythm Ch
88dB, all controls @10
Clean Ch
58dB, all controls @10
CD Input
29dB
Maximum Input Signal Accepted
7 volts peak-to-peak
Solo Channel
Shape Control
Proprietary Circuit
Rhythm Channel
Low Control
20dB range @ 80Hz
Mid Control
15dB range @ 1kHz
High Control
20dB range @ 10kHz
Clean Channel
Low Control
36dB range @ 80Hz
Mid Control
15dB range @ 800Hz
High Control
40dB range @ 10kHz
Power Requirements
120 VAC, 60Hz, 90VA
100/115VAC, 50/60Hz, 90VA;
230VAC, 50/60Hz, 90VA
Size and Weight
19-1/4” H x 21” W x 10-1/4” D, 34 lbs.
The VTX65 is covered with a durable Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Crate continually develops new products, as well as improves existing ones. For this reason, the specifications
and information in this manual are subject to change without notice.
