QuickSpecs
ProLiant BL20p and p-Class system
DA-11411 World Wide — Version 4 — September 19, 2002 13
Options
BL p-Class Server Blade
Enclosures
ProLiant BL p-Class Server Blade Enclosure (ProLiant Essentials Rapid Deployment
Pack Trial)
243564-B21
ProLiant BL p-Class Server Blade Enclosure (8 ProLiant Essentials Rapid Deployment
Pack Licenses)
281404-B21
BL p-Class Interconnects ProLiant BL p-Class RJ-45 Patch panel (pair)
Note: Only one interconnect kit required per server blade enclosure.
230766-B21
ProLiant BL p-Class C-GbE Interconnect Kit (with pair of GbE Interconnect Switches
and two QuadT Interconnect Modules)
Note: Only one interconnect kit required per server blade enclosure.
249655-B21
ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches
and two DualTSX Interconnect Modules)
Note: Only one interconnect kit required per server blade enclosure.
279720-B21
BL p-Class Power options Note: Use p-Class sizing tool to help determine power configuration:
http://activeanswers.compaq.com/aaconfigurator/PowerCalc/BL20p.xls
Single Phase Redundant Power Enclosure with 4 power supplies (NA/JPN)
(Single Phase Power Enclosure holds a maximum of 4 power supplies; no need to
order additional power supplies with this option kit)
239162-001
Single Phase Redundant Power Enclosure with 4 power supplies (Int'l)
(Single Phase Power Enclosure holds a maximum of 4 power supplies; no need to
order additional power supplies with this option kit)
239162-421
3 Phase Redundant Power Enclosure with 6 power supplies (NA/JPN)
(3 Phase Power Enclosure holds a maximum of 4 power supplies; no need to order
additional power supplies with this option kit)
230769-001
3 Phase Redundant Power Enclosure with 6 power supplies (Int'l)
(3 Phase Power Enclosure holds a maximum of 4 power supplies; no need to order
additional power supplies with this option kit)
230769-421
Single Phase Power Enclosure (empty) (NA/JPN)
(Holds up to 4 power supplies; power supplies are not included in this kit)
231710-001
Single Phase Power Enclosure (empty) (Int'l)
(Holds up to 4 power supplies; power supplies are not included in this kit)
231710-421
3 Phase Power Enclosure (empty) (NA/JPN)
(Holds up to 6 power supplies; power supplies are not included in this kit)
231709-001
3 Phase Power Enclosure (empty) (Int'l)
(Holds up to 6 power supplies; power supplies are not included in this kit)
231709-421
Single Power Supply 239161-B21
Facility DC Power Connection 240563-B21
Power Distribution ProLiant p-Class Scalable Bus Bar 240560-B21
ProLiant p-Class Mini Bus Bar 240559-B21
ProLiant p-Class Bus Power Box 240562-B21
Diagnostic Options ProLiant p-Class Diagnostic Station
Note: The Diagnostic Station allows access to the ProLiant BL20p server blade and the
BL p-Class interconnect switch outside of the server enclosure. The option
provides power and a data interface so that "offline" upgrade and diagnostic
functions may be performed.
230743-B21
