QuickSpecs
ProLiant BL20p and p-Class system
DA-11411 World Wide — Version 4 — September 19, 2002 11
Options
Dual NC7780 Gigabit Upgrade Module for ProLiant BL20p 230255-B21 ProLiant BL20p Unique Options
Note: The Dual NC7780 Gigabit Upgrade Module replaces two of the standard NC3163
Fast Ethernet Embedded WOL (Wake On LAN) NICs to two 10/10/1000T
NC7780 NICs.
Note: The GbE Interconnect Switch options support server NIC speeds to 100 Mbps. It
is recommended that the patch panel be used with the Dual NC7780 Gigabit
Upgrade Module if server NIC speeds to 1000 Mbps are required.
ProLiant BL p-Class Server Blade Enclosure (ProLiant Essentials Rapid Deployment
Pack Trial)
243564-B21
ProLiant BL p-Class Server Blade Enclosure (8 ProLiant Essentials Rapid Deployment
Pack Licenses)
281404-B21
ProLiant BL p-Class RJ-45 Patch panel (pair)
Note: Only one interconnect kit required per server blade enclosure.
230766-B21
ProLiant BL p-Class C-GbE Interconnect Kit (with pair of GbE Interconnect Switches
and two QuadT Interconnect Modules)
Note: Only one interconnect kit required per server blade enclosure.
249655-B21
ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches
and two DualTSX Interconnect Modules)
Note: Only one interconnect kit required per server blade enclosure.
279720-B21
Single Phase Redundant Power Enclosure with 4 power supplies (NA/JPN)
(Single Phase Power Enclosure holds a maximum of 4 power supplies; no need to
order additional power supplies with this option kit)
239162-001
Single Phase Redundant Power Enclosure with 4 power supplies (Int'l)
(Single Phase Power Enclosure holds a maximum of 4 power supplies; no need to
order additional power supplies with this option kit)
239162-421
3 Phase Redundant Power Enclosure with 6 power supplies (NA/JPN)
(3 Phase Power Enclosure holds a maximum of 4 power supplies; no need to order
additional power supplies with this option kit)
230769-001
3 Phase Redundant Power Enclosure with 6 power supplies (Int'l)
(3 Phase Power Enclosure holds a maximum of 4 power supplies; no need to order
additional power supplies with this option kit)
230769-421
Single Phase Power Enclosure (empty) (NA/JPN)
(Holds up to 4 power supplies; power supplies are not included in this kit) 231710-001
Single Phase Power Enclosure (empty) (Int'l)
(Holds up to 4 power supplies; power supplies are not included in this kit) 231710-421
3 Phase Power Enclosure (empty) (NA/JPN)
(Holds up to 6 power supplies; power supplies are not included in this kit) 231709-001
3 Phase Power Enclosure (empty) (Int'l)
(Holds up to 6 power supplies; power supplies are not included in this kit) 231709-421
Single Power Supply 239161-B21
Facility DC Power Connection 240563-B21
ProLiant p-Class Scalable Bus Bar 240560-B21
ProLiant p-Class Mini Bus Bar 240559-B21
ProLiant p-Class Bus Power Box 240562-B21
