Clarion DXZ448R - Manual (Page 10)

14
DXZ448R
280-8007-00
English
Radio Operations
Listening to the radio
1. Press the [FNC] button and select the radio
mode. The frequency or PS appears in the
display.
∗ PS: Programme service name
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the following
order:
FM1 ➜ FM2 ➜ FM3 ➜ AM (MW/LW) ➜ FM1...
3. Press the [ a] or [d] button to tune in the
desired station.
Tuning
There are 3 types of tuning mode available, seek
tuning, manual tuning and preset tuning.
Seek tuning
There are 2 types of seek tuning: DX SEEK and
LOCAL SEEK.
DX SEEK can automatically tune in to
receivable broadcast stations; LOCAL SEEK
can tune in to only broadcast stations with a
good reception sensitivity.
1. Press the [BND] button and select the
desired band (FM or AM (MW, LW)).
2. Tune into a station.
∗ If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek
tuning is now available.
∗ If “TA” is lit in the display, TP stations are
automatically sought.
●DX SEEK
Press the [
a] or [d] button to automatically
seek a station.
When the [ d] button is pressed, the station is
sought in the direction of higher frequencies; if
the [
a] button is pressed, the station is sought
in the direction of lower frequencies.
∗ When seek tuning starts, “DX” appears in the
display.
●LOCAL SEEK
If you press and hold the [
a] or [d] button for
1 second or longer, local seek tuning is carried
out. Broadcast stations with good reception
sensitivity are selected.
∗ When local seeking starts, “LO” appears in the
display.
Basic Operations
Adjusting the Z-Enhancer Plus
1. Press the [Z+] button and select the Z-
Enhancer Plus mode to adjust.
2. Press the [A-M] button and turning the
[ROTARY] knob clockwise adjusts in the +
direction; turning it counterclockwise adjusts
in the – direction.
●When “B-BST 0” is selected, you can ad-
just the bass in the range of –3 to 3.
●When “IMPACT 0” is selected, you can ad-
just the bass and treble in the range of –3
to 3.
●When “EXCITE 0” is selected, you can ad-
just the bass and treble in the range of –3
to 3.
∗ Press and hold the [Z+] button for 2 seconds
or longer to change to the “CUSTOM” mode.
Bass/treble characteristics become flat and
the indication “Z+ FLAT” is shown in the
display.
Press the [Z+] button again to change to the
“Z+ OFF” mode.
Adjusting MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low sound area like the normal sound
adjustment function, but emphasizes the deep
bass sound area to provide you with a dynamic
sound.
1. Press and hold the [A-M] button for 1
second or longer to turn on the MAGNA
BASS EXTEND effect. “M-B EX” lights in
the display.
2. Press and hold the [A-M] button for 1
second or longer to turn off the MAGNA
BASS EXTEND effect. “M-B EX” goes off
from the display.
∗ The factory default setting is off.
CT (Clock Time) function
The CT function receives CT data sent from a
RDS station and displays the time. Press the
[DISP] button to switch to the CT display.
∗ If a CT data is not being received, “CT––:––”
appears in the display.
Note:
• CT data is not transmitted in some countries and
by some broadcast stations. Also, in some areas,
the CT may not display accurately.
+DXZ448R-009-ENG 11/12/03, 9:26 PM 14
