33
101992
PARTS LIST
Variably Controlled
Models
This list contains replaceable parts used in your heater. When ordering parts, follow
the instructions listed under Replacement Parts on page 30 of this manual.
KEY PART NUMBER FOR
NO. CG2618PV CG3324PV CG3630PV DESCRIPTION QTY.
1 102230-01 102230-02 102230-03 Front Log (#1) 1
2 102231-01 102231-02 102231-03 Rear Log (#2) 1
3 M11084-26 M11084-26 M11084-26 Screw 5
4 101333-02 101332-01 101332-02 Left Front Branch (#4) 1
5 –– 101333-01 101333-01 Right Front Branch (#5) 1
6 101006-01 101006-01 101006-01 Pilot Bracket 1
7 101330-01 101330-05 101330-06 Front Burner Assembly 1
7-1 101008-01 101008-01 101008-01 Gasket, Crossover Burner 1
7-2 101007-01 101007-01 101007-01 Crossover Burner 1
8 100999-01 100999-02 100999-03 Rear Burner Assembly 1
9 101331-05 101331-06 101331-07 Base Assembly (with decals) 1
10 098271-06 098271-06 098271-06 Ignitor Cable 1
11 097159-02 097159-02 097159-02 Piezo Ignitor 1
12 098867-08 098867-08 098867-08 Gas Regulator 1
13 M11084-38 M11084-38 M11084-38 Screw 2
14 100996-01 100996-02 100996-03 Pipe Nipple 1
15 098354-01 098354-01 098354-01 Control Knob 1
16 102013-01 102013-01 102013-01 Control Rod 1
17 100000-01 100000-01 100000-01 Cotter Pin 1
18 101053-01 101053-01 101053-01 Adapter 1
19 099211-01 099211-01 099211-01 Screw 1
20 101329-12 101329-10 101329-13 Gas Valve Assy. 1
21 100994-01 100994-01 100994-01 Valve Bracket 1
22 101004-10 101004-01 101004-02 Rear Burner Injector 1
23 101004-10 101004-02 101004-06 Front Burner Injector 1
24 101012-01 101012-01 101012-01 Burner Tube 1
25 099387-09 099387-09 099387-09 Pilot Tube 1
26 102255-01 102255-01 102255-01 Strap 1
27 102764-01 102764-01 102764-01 Shield, Heat 1
28 098249-01 098249-01 098249-01 Nut 4
29 099059-02 099059-02 099059-02 O.D.S. Pilot 1
29-1 098594-01 098594-01 098594-01 Ignitor 1
29-2 098593-01 098593-01 098593-01 Thermocouple 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 Warning Plate 1
101054-01 101054-01 101054-01 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 Chain 1
100639-01 100639-01 100639-01 Caution Decal 1
101137-01 101137-01 101137-01 Hardware Kit 1
101416-07 101416-07 101416-07 Information Video 1
GA6060 GA6060 GA6060 Lava Rock 1
