PVB Series Second Floor International Net System Instructions
- 1 of 11-
JSL-Inst046
www.jayprosports.com
Table of Contents
1 Safety ................................................................................................................ 1
2 Specifications .................................................................................................. 1
3 Introduction ..................................................................................................... 2
4 Required Tools ................................................................................................. 4
5 Included Hardware & Components ............................................................ 4
5.1 System Components.............................................................................. 4
5.2 Hardware ................................................................................................. 6
6 Assembly .......................................................................................................... 7
7 Maintenance ................................................................................................ 11
1 Safety
 WARNING: Do not attempt to remove the height adjuster pin if the net is under
tension.
 WARNING: Always use protective padding around each upright during use.
 WARNING: Uprights are heavy. Do not attempt to lift or install without assistance.
 IMPORTANT: Follow all warning labels on equipment.
 IMPORTANT: Inspect for damage before and after each use.
 IMPORTANT: Do not use unless installed into floor anchors.
2 Specifications
U PRIGHT
O UTER
D IAMETER H EIGHT R ANGE
# OF
P OSITIONS W EIGHT
U PPER
U PRIGHT
M ATERIAL
L OWER
U PRIGHT
M ATERIAL
PVB-2500
3-1/2”
(89mm)
6’6” to 8’2”
(1.8m to 2.5m)
16
Pin Stops
145 lbs
(66kg)
Aluminum
6063
Aluminum
6063
