PVB Series Second Floor International Net System Instructions
- 9 of 11-
JSL-Inst046
www.jayprosports.com
8. Set the height of the uprights using the installed height adjust pin (Figure 6-4).
WARNING: Do not attempt to remove the height adjuster pin if the net is under tension.
Figure 6-4: Set upright height.
9. Attach one end of net to anchor strap, then attach other end to winch strap
(Figure 6-5).
Figure 6-5: Attach net to straps.
10. Adjust the length of the anchor strap as necessary to center net on court.
***The net will stretch ~6 – 8 inches when tension is applied so you must factor this
in before applying tension when centering the net.
11. Tension the net by turning the winch handle clockwise 2 . Adjust anchor strap as
necessary to keep net centered.
2 NCAA and NFHS rules stipulate that there be no more than ¾” of sag in the net
headband when fully tensioned.
