JAYPRO SPORTS

FLOOR PLATE ASSEMBLY, FP-90

LIST OF MATERIALS

PIECE NO. PART

NO. DESCRIPTION

QTY.

1

FP-90

FLOOR PLATE ASSEMBLY

1

2

HS2726

HEX HEAD BOLT ½”-13 x 2 ½”

1

3

HN704

HEX NUT ½”-13

1

ASSEMBLY INSTRUCTIONS

TOOLS REQUIRED: Hammer Drill

1 3/8” Masonry Drill Bit

Mixing

Container

And

Water

Small

Vacuum

Cleaner

Stiff Circular Brush (Bottle Brush)

Putty

Knife

Or

Scraper

Rag

Or

Other

Absorbent

Material

Regular

Power

Drill

1 3/8” Wood Drill Bit

5/32”

Drill

Bit

Screwdriver

With

Wide

Blade

¾ lb. (Approx) Non Shrink Anchoring Cement

NOTICE

The fp-90 floor plate assembly is manufactured with a removable center section which
can be replaced in the event that the internal threads are damaged. Upon original
installation of the floor plates or replacement of threaded sections, be sure that the
replacement threaded sections are installed very tightly using a thread locking sealant to
prevent easy removal or tampering.

PLEASE READ INSTRUCTIONS IN THEIR

ENTIRETY BEFORE BEGINNING INSTALLATION

1) Locate and mark the center locations of the floor plates using the layout diagram in

the equipment instructions sheet. Re-check all center locations for accuracy before
installing the floor plates.

2) Using the 1 3/8” wood drill bit, drill a hole in the wood floor and the wood sub floor

down to the concrete base as shown in figure ‘a’.

3) Screw the ½” bolt with the nut into the bottom of the floor plate. Adjust the bolts so

it will reach ½” x ¼” from the bottom of the hole when the floor plate is in place.
Tighten the nut against the floor plate bottom to lock the bolt into place. In some
cases the bolt supplied with the fp-90 unit will not reach to the bottom of the hole in
the cement. If this happens, a longer bolt or threaded rod should be used to insure
reaching the bottom.

4) Next, completely remove the dust from the hole by using a vacuum cleaner, air

compressor, or battery filler.

5) Fill the hole with water. Scrub the sides and bottom with a stiff brush, such as a

bottlebrush. This is very important.
