Rev-A 11/12 Page 3 of 16
ITEM IMAGE DESCRIPTION QTY
7 2” x 4” LOWER CORNER FITTING 2
8
SOCCER WHEEL KIT
P/N: SGP-NWK
(ONE KIT FITS TWO GOALS,
COMES WITH ITS OWN INSTRUCTION
PACKAGE)
5”LONG x 3/8” THICK NUT BAR
1
9 BACKSTAY LOCK NUT BAR 2
10
PRE-ASSEMBLED SPRING LOADED
BRACE ASSEMBLY
2
11 1/8" OD x 1 1/2" COTTER 2
12
CLEVIS PIN 3/4" OD x 5" LENGTH, ZP
STEEL
2
13 3/8"-16 NYLON LOCK NUT, SS 4
ITEM IMAGE DESCRIPTION QTY
