JAYPRO SPORTS
WALL MOUNTED LADDER, WML-100
LIST OF MATERIALS
ITEM PART NO. DESCRIPTION QTY.
1 WML101 LADDER 1
2A WML103L FRAME HANGER-LEFT 1
2B WML103R FRAME HANGER-RIGHT 1
3 WML4 WOOD WALL PAD 6
4 CN0001 CHAIN x 4 FT 2
5 WML105 BRACKET 4
6 WML102 BRACE TUBE 2
7 HM6090 3/8” x 6” TURNBUCKLE 2
8 HS5033 HX HD SCREW ½”-13 x 3” 6
9 HN5038 ½” FLANGE LOCK NUT 18
10 EP0009 1 3/8” PLASTIC PLUG 6
11 EC0034 2 x 4 PLASTIC PLUG 4
12 HM6052 3/8” QUICK LINK 4
13 HS5116 ½-13 x 2 ½ HEX HEAD BOLT 2
14 HB5045 CARRIAGE BOLT ½-13 x 2 ½” 12
15 HS5144 SCREW #8 x 1” 8
16 HM6071 ½-13 EYE SOCKET 2
17 HW2044 ½ SAE FLAT WASHER 2
18 HW1245 ½’’ SPLIT LOCK WASHER 2
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED: 2 EA MEDIUM ADJUSTABLE WRENCHES, RUBBER
MALLET, PHILLIPS SCREW DRIVER, LEVEL
IMPORTANT NOTE
Proper installation of the wood pads is critical to the safe use and continued high
performance of this apparatus. Jaypro strongly recommends you use the services of a
qualified local contractor familiar with your building’s wall structure and strength. You
or your contractors are responsible for selecting fasteners appropriate for your wall
construction. Minimum ½” diameter anchor bolts are recommended.
1) See “view A-A”. All carriage bolts 1/2”-13 x 2 ½” (item 14) must be assembled
thru the wood pads (item 3) before pads are mounted onto the walls. Use a rubber
mallet to firmly seat each carriage bolt head into the rear side of the wood pad.
2) Lay-out locations and carefully install the wall pads (item 3) as illustrated. Install
the four brackets (item 5) and two frame hangers (items 2a & 2b) as indicated
then firmly tighten to the carriage bolts (item 14) with a 1/2” flange lock nut (item
9). Note orientation of interior frame hanger brackets (left & right).
3) Assemble the two diagonal brace tubes (item 6) as shown and firmly tighten the
fasteners. Loosely assemble the opened turnbuckle (item 7), quick link
connectors (item 12) and anchor chain (item 4) to each upper wall pad bracket and
