Jaypro Sports FBGP-600 - Manual (Page 10)

DETAIL A
DETAIL B
1
1
2
2
3
3
4
4
A A
B B
1 1 OF
PHONE:
800.243.0533 (TOLL FREE)
860.447.3001 (LOCAL)
FAX:
800.444.1779 (SALES)
860.440.0628 (ENG.)
FBGP-600 FOOTING SPECIFICATIONS
PAGE TWO
B N/A
DC
THIS DRAWING IS THE SOLE PROPERTY OF JAYPRO SPORTS INC. AND MAY
NOT BE REPRODUCED WITHOUT WRITTEN PERMISSION OR CONSENT
JAYPRO SPORTS, LLC, 976 HARTFORD TURNPIKE, WATERFORD, CT 06385 USA
www.jaypro.com
DESCRIPTION
PART NUMBER DWN BY
-
REV
7/14/2006
DATE SIZE SHEET SCALE
CHKD BY
BTS
A
B
FBGP-600
FOOTBALL GOAL
FOOTING SPECIFICATIONS
FIGURE 2
36 in
60 in
CONCRETE
12 in
TYP. 4 SIDES
8 in
11 in
(REF)
GOOSENECK
3/4" RE-BAR
(NOT INCLUDED)
IT IS STRONGLY RECOMMENDED THAT
THE POURED FOOTING BE REINFORCED
WITH A MINIMUM OF 6 PIECES OF
3/4" x 66" RE-BAR
12
11
9
13
10
NUT PREINSTALLED
