Page 2
REV-
7/14/11
Page 2 of 6
JAYPRO SPORTS
2 ROW, 27 FT ALUMINUM TIP n’ ROLL BLEACHER PARTS LIST
ITEM
PART #
DESCRIPTION
BLCH-227TRG
BLDP-227TRG
1
BLAL-2RL
ALUMINUM 2-ROW BLEACHER LEG
5
5
2
BLAL-3RX-1
1/4" x 1-1/4" FLAT X-BARS (BLAL-321RX)
8
8
3
AR5111
9-1/2" x 1-1/2" x 27' STADIUM PLANK
3
4
4
CS0011
1/2"-13 x 1-1/2" THREAD x 4" DIA. CASTER WHEEL
4
4
5
RR5005
RUBBER BUMPER
15
15
6
HN5038
1/2"-13 FLANGE NUT
18
18
7
HW2050
3/8" FLAT WASHER, ZP
15
15
8
HS287
3/8"-16 x 1-1/4" HEX HEAD CAP SCREW, ZP
15
15
9
HN5042
3/8"-16 FLANGE HEX NUT, ZP
15
15
10
HB5054
5/16"-18 x 1-1/4" CARRIAGE BOLT, ZP
30
40
11
HN5046
5/16"-18 FLANGE NUT, ZP
30
40
12
AR5044
5/16" BOLT CLIP
30
40
13
HS5035
#8 x 1/2" PAN HEAD PHILIP SCREW SELF DRILL, ZP
12
16
14
AR5045A
9-1/2" ALUMINUM SEAT PLANK END CAP
6
8
15
HW2044
1/2" FLAT WASHER
10
10
16
HS2884
1/2"-13 x 1-1/2" HX HD CAP SC, ZP
10
10
Kit # →
BLTR-227RK
BLDP-227RK
Box # →
1
1
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
