INTRODUCTION
These instructions outline the assembly and use of the Pitcher’s Screen Model ps‐84. If you need
additional information or support in the assembly and use of the Pitcher’s Screen you can reach the
Jaypro Sports customer support team, Monday through Friday, 8:00 AM to 5:00 PM Eastern time at 800‐
243‐0533.
Replacement nets are available through your dealer or by calling Jaypro Sports.
SAFETY
All netting deteriorates through use and exposure to the elements. For safe operation and continued
high performance from this equipment, inspection and maintenance must be performed before each
use. Inspect the net for broken mesh, tears, or other signs of weakness. Questionable nets should be
immediately removed from service and replaced.
Use of this equipment other than intended, may be hazardous. Alteration or modification of equipment
may be hazardous. For repair or replacement, please call your dealer or Jaypro Sports.
EQUIPMENT AND MATERIALS
Allen Wrenches Wrench Set Optional‐Loctite Thread Lock
Wrench Set Rubber Mallet
BEFORE YOU START
Check to confirm that you’re Pitcher’s Screen has shipped with all hardware. If any hardware or
components are missing, contact the Jaypro Customer Support Team.
www:Jaypro.com
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 LEG BASE 11 2 WHEEL
2 1 WHEEL BASE 12 1 NET
3 1 BASE PIPE 13 2 TUBE CAP
4 1 CROSS PIPE 14 11 M8 x 40 mm SCREW
5 1 UPRIGHT 15 11 M8 CURVED NUT
6 1 LOWER UPRIGHT 16 2 M12 x 65 mm HEX BOLT
7 1 TOP UPRIGHT 17 2 M12 WASHER
8 1 TOP CROSSBAR 18 2 M12 NUT
9 2 TEE 19 2 #14 SELF TAPPING SCREW
10 2 WHEEL BRACKET
