When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
Page 6
REF. NO.
DESCRIPTION
QTY.
PART NO.
1
CONTROL BASE (MODEL SSP-10-1)
1
11833
CONTROL BASE (MODEL SSP-H-10)
11835
2
CONTROL BASE BACK COVER
1
11719
3
CONTROL PANEL (INCLUDED #4 )
1
11837
4
CONTROL PANEL BOLT
3
11024
5
CONTROL BASE INFLATION CAP
1
11831
6
CONTROL PANEL BOLT WRENCH
1
11053
7
SPA/COVER INFLATION HOSE
1
11830
8
SPA CONTROL INLET/OUTLET O-RING
2
11699
9
SPA CONTROL AIR INLET O-RING
1
11687
10
SPA DRAIN PLUG
1
11696
11
SPA DRAIN VALVE ADAPTOR
1
11713
12
FILTER CARTRIDGE HOUSING
2
11798
13
FILTER CARTRIDGE
2
11692
14
FILTER CARTRIDGE HOUSING LID
2
11797
15
INLET/OUTLET PLUG
3
11739
16
SPA TUB
1
11843
17
SPA COVER
1
11841
18
SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
1
11689
19
GROUND CLOTH
1
11717
20
CHEMICAL DISPENSER
1
10883
21
TEST STRIPS
1
11855
22
WRENCH
1
11742
23
PRESSURE GAUGE
1
11741
24
SUCTION FITTING
3
11695
25
INFLATION HOSE ADAPTOR
1
11829
26
MALE BUCKLE
6
11698
27
FEMALE BUCKLE
6
11799
SPA SUCTION FITTING
Self-contained spa fi ttings. – For multiple outlet use only. – Wall mounting only.
Replace suction fi ttings within 3 installed year. – Tool required: screwdriver.
Spa suction fi tting maximum fl ow rate: 8.5 gpm (510 gph)
•
Check suction strainer fi tting and fasteners for damage or tampering before each use of the spa.
•
For service and winterization instructions refer to “Maintenance” and “Storage” sections.
•
Read and follow all instructions, save these instructions for future reference.
