Monitoring Hub Performance 2-13
Using the SEHI100TX Hub View
Name
This text Þeld can help identify the module, or device; the information entered
here does not appear anywhere else in the Hub View.
To edit the Module Name:
1. Highlight the text in the Name box and type in a new name.
2. Press Enter or Return on the keyboard to save your changes.
Active Users
This Þeld is not supported by the SEHI100TX-22.
Module Type
The type of module you are viewing.
Checking Repeater Status
The Repeater Status window ( Figure 2-8 ) allows you to assign a name to the
SEHI100TX-controlled HUBStack as a whole. To open the Repeater Status
window:
1. Click on the Device button to display the Device menu.
2. Drag down to Repeater Status and release.
Figure 2-8. The Repeater Status Window
Name
This Þeld can help identify the SEHI100TX-controlled stack as a whole; the
information entered here is not displayed anywhere else in the Hub View.
To edit the Repeater Name:
1. Highlight the text in the Name box and type in a new name.
2. Press Enter or Return on the keyboard to save your changes.
