Black plate (48,1) Cadillac SRX Owner Manual - 2011
10-48 Vehicle Care
Mini Fuses Usage
4 Not Used
5
Engine Control
Module Run Crank
7
Post–Catalytic
Converter O2
Sensor
8
Pre–Catalytic
Converter O2
Sensor
9
Engine Control
Module Powertrain
10 Fuel Injectors–Even
11 Fuel Injectors–Odd
13 Washer
16
Instrument Panel
Cluster/Malfunction
Indicator Lamp/
Ignition
17 Air Quality Sensor
18 Headlamp Washer
Mini Fuses Usage
19
Transmission
Control Module Run
Crank
20
Rear Electrical
Center Run Crank
23 Heater Motor
30 Switch Back Light
32
Battery Sense
(Regulated Voltage
Control)
33
Adaptive Forward
Lighting/Adaptive
Headlamp Leveling
Module
34
Body Control
Module 7
35
Electronic Brake
Control Module
46
Low Beam
Headlamp‐Right
47
Low Beam
Headlamp‐Left
Mini Fuses Usage
50 Front Fog Lamps
51 Horn
52
Fuel System Control
Module
53 Headlamp Level
54
Sensing Diagnostic
Module Ignition
55
High Beam
Headlamp–Right
56
High Beam
Headlamp–Left
57
Ignition Steering
Column Lock
65
Trailer Right
Stop Lamp
66
Trailer Left
Stop Lamp
67 Spare
68 Spare
69 Spare
