NO. DESCRIPTION 1500 3000 5000 6000 7500 9000 1000012000
1 DRUM ASSY ● ● ◆ ● ● ● ◆ ●
2 MOTOR CAPSTAN (D-35) ● ● ● ◆ ● ● ● ◆
3 BELT CAPSTAN ◆
4 BASE ASSY A/C ● ● ● ● ● ● ● ◆
5 HEAD F/E ● ● ● ● ● ● ● ◆
6 ARM ASSY IDLER
◆
7 HOLDER ASSY PINCH
◆ ◆
8 BAND ASSY TENSION ◆
9 HOUSING ASSY ▲ ▲ ▲ ▲ ▲ ▲ ▲ ◆
10 CAPSTAN SOFT BRAKE ◆ ◆
Reference:
◆: Changing ●: Cleaning ▲: Checking
Notes:
•
Check the running path adjustment when you change items 1, 2, 4, 5 and 10.
• Check the back tension when you change Band Assy Tension.
28
ADDITIONAL
INFORMA
TION
SERVICE GUIDE TABLE
VIDEO HEAD CLEANING
• Dirt accumulating on the head after a long period of time can cause the playback picture to
become blurred or broken up. High quality video cassette tapes will not normally deposit dirt
onto the video head, but old or damaged tapes might. Clean the video heads with a
commercially available video heads cleaning tape.
Unit is Hour.
