LIGHTOLIER*

Lighting Systems

SQ6-3

Page 1 of 2

6" X 6" Square T8 3-Lamp per 4-Foot Section

Ordering Information

Family

Lamps

Length

Type

Mounting

Shielding

Voltage

Options

SQ6

3

B

3

= 3-Light

= 4-Foot

= 8-Foot

B

= Bi-directional

P =

W

Suspended

= Wall

S

= Straight Blade Louver

C

= Paracube 1/2"

L

= Lens K19

N

= None

P

= Parabolic Louver

Complete ordering instruction below.

1

= 120v

2

= 277v

3

= 347v

D1

= Dimming 120v

D2

= Dimming 277v

E1

= Emergency 120v

E2

= Emergency 277v

X4

= 4th Wire

X5

= 5th Wire

Blank

= No Opt.

DS

= Dual Switch

Features

1. Housing:

20 gauge pre-painted die formed steel. Weldless, die-cast bulkheads

allowing casting to casting luminaire connection. ABS Cast plastic end caps,

painted white to match housing, fastenerless attachment.

2. Lamp:

Three F32T8 fluorescent lamps per 4-foot section. Provided by others.

3. Reflector:

Precision die-formed high reflecfance whife pre-painfed sfeel.

4. Straight Blade Louver:

Liff and shiff, consfrucfed from die-formed aluminum

and finished fo mafch fhe housing. Louver blades are 1" (2.54cm) high on 1-1/8"

(2.86cm) confers.

5. Lens:

Exfruded 100% acrylic clear prismafic lens.

6. Paracube Louver:

Liff and shiff, injecfion molded mefalized louver wifh

1/2" (1.27cm) X 1/2" (1.27cm) cubes.

7. Parabolic Louver:

Liff and shiff, consfrucfed of die-formed semi-specular

aluminum. Louver blades are 1" (2.54cm) high on 1-1/2" (3.81cm) confers.

Electrical

Electronic Ballast:

3 conducfor, 18 gauge wire. Color-coded quick connecfors

allow easy connecfion for modular fixfures. Power feed is 18 gauge whife cord.

Facfory insfalled ballasf disconnecf allows fhe ballasf fo be disconnecfed from and

reconnecfed fo incoming power under load wifhouf fuming fhe enfire circuif off.

Dimming:

Advance MarkX, use Advance compafible fwo-wire confrol (no exfra

lead required).

Emergency Battery Pack:

450 Lumens @ 90min.

Mounting

Cable Mounting:

(not shown) 4-1/2" (11.43cm) diameter canopy finished whife

enamel, 1/16" (0.16cm) diamefer sfainless sfeel aircraff cable adjusfable up fo 36"

(91.44cm) Draw-fighf connecfor fo creafe hairline seam befween joiner modules.

Stem Mounting:

(not shown) 4-1/2" (11.43cm) diameter canopy finished whife

enamel, 1/2" (1.27cm) diamefer sfem. Sfandard lengfh is 24" (61.30cm) from fhe

ceiling fo the top of the lighting fixture, can be cut to length on the job. Self­

aligning swivel provides adjusfabilify up fo 42° of slopes.

Wall Mounting:

Precision die-formed sfeel brackef sysfem fhaf hooks and locks

onto the wall, painted white.

Finish

Pre-painfed fexfured whife finish. Shipped wifh plasfic adhesive film protecfor.

Options and Accessories

Dual Switching:

Order fhe DS option for separafe row swifching. DS option comes

complete with the 4th through wire option.

4

and 5 wire:

Order X4 for EM baffery. Eor non-sfandard dimming options, order X5

option for Advance Mark VII, DALI and ESI. Order X4 for Lufron Hi-Lume and ECO-10.

Consulf facfory for any addifional wiring condifions.

Ordering Instructions

Individual Fixtures:

1.

Order number of Modules required.

2.

Order one Power Peed End Sef (Cable or Sfem) per Module.

Continuous Runs:

1.

2.

3.

4.

5.

Defermine run lengfh.

Order fhe appropriafe number of Modules for fhe complefe run.

Order one Power Peed End Sef (Cable or Sfem) per run.

Order one Cable or Sfem Assembly per Modules minus one per run.

Eor runs fhaf exceed amperage limifs, order fhe appropriafe number of Cable/

Cord Assemblies (not required for sfem).

Labels

UL, cULand I.B.E.W.

Job Information

1 Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

631 Airport Road, Pall River, MA 02720 • (508) 679-8131 • Pax (508) 674-4710

We reserve the right to change details of design, materials and finish.

www.lightolier.com © 2008 Philips Group • E1208

Lightolier is a Philips group brand
