C^D English

SBC BA 120

^ Explanation of Controls

SBC BA 120

Instruction for use Philips mini*speakers

1. Introduction

CONGRATULATIONS !You have just bought a
sophisticated mini stereo loudspeaker set.This
set gives you the opportunity to share your

favourite music with your friends.To ensure the

best performance of your mini stereo
loudspeakers, please read this document

carefully.

2. Features

•Trackball volume control
• Dynamic bass boost (DBB)

• Built-in 4 Watt amplifier
• Easily portable
• Battery or mains operated
• Bass reflex system

3. Explanation of controls

1. Power on/off

2. Trackball volume control

3. Dynamic bass boost (DBB)

7

.

4. Power indication LED
5. Bass reflex port
6. Audio input cable
7. AC/DC adaptor input

8. Output jack to left speaker

9. Audio input cable for left speaker

10. Battery cover

4. Installation

1. Connect the stereo signal to the Mini speaker

loudspeaker with the HiFi cable coming from
the right speaker as shown in figure I.

2. SBC BA 120 powered by batteries. Insert six

batteries (R6.‘AA') in the battery

compartment on the right speaker module,
ensuring that the polarity is correct (see figure

I.)

3.SBC BA 120 powered byAC/DC adaptor.

Insert the AC/DC adaptor plug into the DC

input jack (7) on the rear of the right speaker.

Then plug the AC/DC adaptor into a standard

mains power wall outlettThe voltage
mentioned on the rating label of the AC/DC

adaptor should be in line with the voltage of
the wall outlet.

5. Operation

1. Switch on the mini speakers: the amplifier is

now activated.

2. Position both speakers so that you can enjoy

the full audio range sound.

3. Adjust the speakers’ volume level control to

a comfortable listening level.

4. When you no longer require the speakers,

turn the power switch off to conserve
batteries.

5. When the battery power runs low. the

battery indication (4) becomes less bright

and the sound quality degrades: when this
happens replace the batteries.

6. By not switching on the power the mini

speakers can be used as passive speakers: in
this case the speakers’ volume can be
controlled by adjusting the volume of your

audio source.

Positioning the mini speakers

Position the left speaker on the left side of your

listening area, and the right speaker on the right
side.

Specifications

Frequency range
Impedance passive
Impedance active
Maximum output power

Weight

Power supply

80..20 000 Hz
A Li

150

Li

2x4 W

885 g

6xR6('AA’) or AC/

DC adaptor 9V/500 mA

8. Precautions

•This mini speaker system works only on a 9V

DC supply. If the system has not being used

or will not be used for some time, please

remove the batteries to prevent leakage and

corrosion.

• Do not leave the mini speakers near heat

sources. Do not expose to direct sunlight,

excessive dust, moisture, rain or any kind of

mechanical shock.

• Do not use alcohol, thinner or petroleum-

based substances to clean the speakers.

• If fluid spills into the speakers, remove the

batteries immediately and consult an
authorised dealer.

• Keep the mini speakers away from TV or

credit cards using magnetic coding to prevent

any damage caused by the speakers’ magnets.
