2 Simon XTi Designer Template Installation Sheet
Figure 3: Designer template back
E
F
5. Turn over the template to the front (cosmetic) side.
6. Position the two alignment holes in the template (A in
Figure 1 on page 1) over the two pins (C in Figure 2 on
page 1) located on the cover of the panel.
7. Lightly press down on the left side of the template. Once
located, reach under the template and remove the
remainder of the paper backing (F in Figure 3 above).
8. Press down with your thumb on the template from left to
right, removing any air bubbles and ensuring proper
adhesion.
9. After the template is adhered to the front of the panel,
remove protective film from front of template by pulling on
tab (B in Figure 1 on page 1) in upper right hand corner.
10. Replace the plastic trim ring on panel.
