IC Realtime 600TVL License Plate Capture Camera (ELID1) User Manual
Page 5
- 5 -
Guidelines
These following installation guidelines must be followed for proper and
consistent license plate capturing:
• The EL-ID1 must be installed and mounted in an area which is free
from falling objects.
• The mounting surface must be secure to handle the weight of the
camera and free from vibration.
• When the camera is mounted and initial setup is ready it would ensure
consistency to park a vehicle at the capture point for testing purposes.
CAUTION
Install the EL-ID1 in an appropriate location which does not exceed any
environmental conditions as noted on the specifications (pg.6).
