Table 2-2 Configuration Page
Callout Area on the screen Information or capability that the area provides
1 HP EWS tabs and menus For more information, see Navigating through the HP Embedded Web
Server .
2 Printer Information Lists the serial number, version numbers, and other information for
the device.
3 Installed Personalities and
Options Lists:
■ Version and TCP/IP address for all network devices connected to
the product (Jetdirect or internal Jetdirect)
■ All of the printer languages that are installed (such as printer
command language [PCL] and PostScript® [PS])
■ Options that are installed in each DIMM slot and EIO slot
■ USB devices that can be connected to a printer used as a host
USB controller, such as mass storage devices, card swipes, or
keypads
4 Memory Lists the memory information, PCL Driver Work Space (DWS), and
resource saving information.
5 Security Lists the status of the control-panel lock, disk write-protect options,
and direct-connect (USB or parallel) ports.
You can change the status of the Direct Connect ports on the
Security screen under the Settings tab by selecting or clearing the
Disable Direct Ports check box.
6 Paper Trays and Options Lists the size and type of media that is specified for each of the trays
in the product. If a duplexing unit or any paper-handling accessories
are installed on the product, information about those devices is also
listed here.
7 Calibration Information Lists the last color-plane registration (CPR) page count, the last CPR
page-count date, the last page count (in engine cycles) for DMAX/
DHALF, and the last DMAX/DHALF page-count date.
Color plane registration occurs when new print cartridges are installed
to compensate for any slight variations that might occur in cartridge
circumference.
DMAX is a density calibration of each print cartridge color at 100%
coverage; DHALF is also a density calibration of each print cartridge
color, but as a halftone instead of a full color. During halftone printing,
the dots of toner are spread out, and coverage of the toner is less
than 100%.
8 Color Density Lists the cyan, magenta, yellow, and black (CMYK) values for
highlights, midtones, and shadows.
