QuikRuler III 25

3. To measure another segment, click on its starting and ending points. You do not

have to click on the

button first.

NOTE: Each measured segment is automatically summed with previously measured
segments when in Length Segment Mode.

4. To start a new sum, click on the

button.

Measuring a Continuous Length

Use the

function to measure a curved length.

1. Click on the

button.

2. Press the stylus tip down on the starting point of the length and hold.
3. Trace along the length of the segment until you reach the ending point.
4. Lift the stylus tip.

QuikRuler III displays the length of the line.

5. If the segment you are measuring is a straight line, click on the starting point of the

line, lift up the stylus and click on the ending point.
