ELECTRIFLY TRITON COMPUTERIZED CHARGER
R/C BATTERY CHARGE/DISCHARGE CHART
BATTERY SPECS CHARGING DISCHARGING
Break-in Standard Peak
charge rate charge Quick Detection Discharge Discharge
Type Size Capacity 0.1C rate minutes rate at 1C charge rate Sensitivity current cutoff voltage
NiCd N/AAA 50mAh 0.1A 30 0.1A 0.1A (2C)
110mAh 0.1A 66 0.1A 0.2A (2C)
150mAh 0.1A 90 0.2A 0.3A (2C)
250mAh 0.1A 150 0.3A 0.5A (2C)
300mAh 0.1A 180 0.3A 0.6A (2C)
AA 500mAh 0.1A 300 0.5A 1.0A (2C)
600mAh 0.1A 360 0.6A 1.2A (2C)
700mAh 0.1A 420 0.7A 1.4A (2C)
800mAh 0.1A 480 0.8A 1.6A (2C)
A 1000mAh 0.1A 600 1.0A 2.0A (2C)
1100mAh 0.2A 330 1.1A 2.2A (2C)
1200mAh 0.2A 360 1.2A 2.4A (2C)
1300mAh 0.2A 390 1.3A 2.6A (2C)
1400mAh 0.2A 420 1.4A 2.8A (2C)
Sub-C 1400mAh 0.2A 420 1.4A 4.2A (3C)
1500mAh 0.2A 450 1.5A 4.5A (3C)
1800mAh 0.2A 540 1.8A 5.0A
1900mAh 0.2A 570 1.9A 5.0A
2000mAh 0.2A 600 2.0A 5.0A
2400mAh 0.3A 480 2.4A 5.0A
NiMH N/AAA 300mAh 0.1A 180 0.3A 0.6A (2C)
500mAh 0.1A 300 0.5A 1.0A (2C)
600mAh 0.1A 360 0.6A 1.2A (2C)
700mAh 0.1A 420 0.7A 1.4A (2C)
AA 1200mAh 0.1A 720 1.2A 2.4A (2C)
1300mAh 0.1A 780 1.3A 2.6A (2C)
1400mAh 0.1A 840 1.4A 2.8A (2C)
1500mAh 0.2A 450 1.5A 3.0A (2C)
1600mAh 0.2A 480 1.6A 3.2A (2C)
A 1500mAh 0.2A 480 1.6A 3.2A (2C)
1700mAh 0.2A 510 1.7A 3.4A (2C)
1800mAh 0.2A 540 1.8A 3.6A (2C)
1900mAh 0.2A 570 1.9A 3.8A (2C)
2000mAh 0.2A 600 2.0A 4.0A (2C)
Sub-C 3000mAh 0.3A 600 3.0A 5.0A
3300mAh 0.3A 660 3.3A 5.0A
C÷5 when checking
the battery’s ability
to hold it’s rated
capacity.
2C for quick
discharges.
(0.2-0.3A when
testing Rx and Tx
batteries for useful
flight time)
same as above same as above 3-5mV per cell
(1.1 volts per cell
when testing Rx
and Tx
batteries for useful
flight time)
0.9 volts per cell
8-10mV per cell
BATTERY SPECS CHARGING DISCHARGING
Standard Maximum
charge rate Quick charge voltage Discharge Discharge
Type Capacity at 0.3C rate at 0.7C per cell current (C÷5) cutoff voltage
Lithium-Ion 600mAh 0.2A 0.4A 0.1A
or Lithium- 1200mAh 0.4A 0.8A 4.2 volts 0.2A 3.0 volts per cell
Polymer 1800mAh 0.6A 1.3A 0.4A
C÷5 discharge current to compare battery to manufacturer
specs - 2C max. for speed
BATTERY SPECS CHARGING DISCHARGING
Standard Maximum
charge rate Quick charge voltage Discharge Discharge
Type Capacity at 0.1C rate at 0.3C per cell current (C÷20) cutoff voltage
Lead-acid 4.5Ah 0.5A 1.5A 0.3A
7Ah 0.7A 2.3A 2.5 volts 0.4A 1.75 volts per cell
10Ah 1.0A 3.3A 0.5A
C÷20 discharge current to compare battery to manufacturer
specs - 1C max. for speed
For a 500mAh battery: “1C” = 500mA or 0.5 amps
For a 1300mAh battery: “1C” = 1300mA or 1.3 amps “2C” = 1000mA or 1.0 amps (500x2)
“2C” = 2600mA or 2.6 amps (1300x2) “C/5” = 100mA or 0.1 amps (500÷5)
“4C” = 5200mA or 5.2 amps (1300x4)
“C” equals the capacity rating of a battery as printed on it’s label.
