34. Glue the wing fairing in place on the wing with
6-minute epoxy.
❏
1. Cut away the covering from the rear of the fuselage to
reveal the slots for the fin, stab and the holes for the
pushrods. There are two holes for the pushrods on the left
side of the fuselage and one hole on the right side.
❏
2. Bolt the wing onto the fuselage.
❏
3. Slide the horizontal stabilizer into the slot in the
fuselage.
❏
4. Measure from the end of the stab to each wing tip and
from the center of the fuselage out to the end of the stab as
shown in the sketch.
❏
5. Once you have the stab properly positioned, mark the
outline of the fuselage on the top and bottom of the stab.
Remove the stab from the fuse. Use a sharp #11 hobby knife
or use the Expert Tip that follows to cut the covering from
the stab along the lines you marked. Use care to cut only
into the covering and not into the wood.
FUSELAGE ASSEMBLY
12
