Before starting to build, take an inventory of this kit to make sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or missing parts, use the part names exactly as they are written in
the Kit Contents list.
Great Planes Product Support
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Telephone: (217) 398-8970, ext. 5
Fax: (217) 398-7721
E-mail: [email protected]
KIT INSPECTION
1. Radiator
2. Fuselage
3. Battery Hatch
4. Hook & Loop Material
5. Exhaust (L&R)
6. Machine Gun
7. Outer Wing Struts (2 long, 2 short)
8. Long Cabanes (2)
9. Short Cabanes (2)
10. Landing Gear Supports (2)
11. Main Landing Gear
12. Stabilizer & Elevator
13. Fin & Rudder
14. Top Wing
15. Bottom Wing
(3) 3 x 6mm Machine Screws
(8) 2 x 7mm Self-Tapping Screws
(4) 35mm Aileron Pushrod
(4) 25mm Heat-Shrink Tubing
(4) #1 Strut Mounts
(2) #2 Strut Mounts
(2) #3 Strut Mounts
(1) Plywood Motor Mount
(3) Aluminum Tubes
(3) 3 x 26mm Machine Screws
(7) 3mm Washers (2) 460mm Pushrods
(4) Control Horns
(2) Screw-Lock Pushrod Connectors
(2) Screw-Lock Nylon Retainers
(1) Double-Sided Tape
(2) Aileron Servo Hatch
(1) 3 x 18mm Machine Screw
(4) Straight Control Horn
(1) Hook & Loop Material
(14) 2 x 8mm Self-Tapping Washer
Head Screw
(2) 100mm Pushrod Z-Bend One End
(2) 100mm Pushrod L-Bend One End
(2) Plastic Pushrod Retainer
(2) 2 x 9mm Machine Screw
(2) 2mm Washer
(2) 2 x 5mm Flat Head Machine Screw
Kit Contents (photographed)
Kit Contents (not photographed)
KIT CONTENTS
