3. Attach the other end of the landing gear supports to the
bottom of the wing with two 2 x 8mm washer head self-
tapping screws. Once all the screws are installed they can
be tightened.
❏
4. Glue the exhaust to the side of the fuselage.
❏
5. Slide the prop shaft and collet onto the output shaft of
the gear-drive. The collet has a tapered hole through it. The
side with the larger hole goes on first. Use clear tape to
attach the radiator to the front of the fuselage so that the
prop adapter is centered in the opening of the radiator.
❏
6. Remove the prop nut and washer and install the 10x4.5
propeller. Reinstall the washer and prop nut and tighten the
nut securely.
❏
7. Insert the battery in the battery compartment and
secure it with the hook and loop material. Trim the excess
hook and loop material.
❏
8. Slide the battery hatch into position. Note that the lip
slides under the front of the fuselage and the aft end is held
on with two magnets.
15
