Great Planes S.E.5a EP ARF - GPMA1140 - Manual (Page 4)

• When you see the term test fit in the instructions, it means
that you should first position the part on the assembly
without using any glue, and then slightly modify or
custom fit the part as necessary for the best fit.
• Photos and sketches are placed before the step they
refer to. Frequently you can study photos in following
steps to get another view of the same parts.
• The stabilizer and wing incidences and motor thrust
angles have been factory-built into this model. However,
some technically-minded modelers may wish to check
these measurements anyway. To view this information
visit the web site at www.greatplanes.com and click on
“Technical Data.” Due to manufacturing tolerances
which will have little or no effect on the way your model
will fly, please expect slight deviations between your
model and the published values.
Fuse = Fuselage
Stab = Horizontal Stabilizer
Fin = Vertical Fin
LE = Leading Edge
TE = Trailing Edge
LG = Landing Gear
Ply = Plywood
" = Inches
mm = Millimeters
ESC = Electronic Speed Control
Replacement parts for the Great Planes S.E.5a EP ARF are
available using the order numbers in the Replacement Parts
List that follows. The fastest, most economical service can be
provided by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico ® web site at
www.hobbico.com. Choose “Where to Buy” at the bottom
of the menu on the left side of the page. Follow the
instructions provided on the page to locate a U.S., Canadian
or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa
® or MasterCard ®
number and expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason contact Product
Support by e-mail at [email protected], or by
telephone at (217) 398-8970.
Description How to Purchase
Missing pieces Contact Product Support
Instruction manual Contact Product Support
Kit parts listed below Hobby Supplier
Replacement Parts List
GPMA3000 ..............Upper Wing Set
GPMA3001 ..............Lower Wing Set
GPMA3002 ..............Fuse Set
GPMA3003 ..............Tail Surface Set
GPMA3004 ..............Cowl
GPMA3005 ..............Cabanes Set
GPMA3006 ..............Interplane Set
GPMA3007 ..............Machine Gun Set
GPMA3008 ..............Exhaust Stack Set
GPMA3009 ..............Landing Gear
GPMA3010 ..............Wheels (2)
GPMA3011 ..............Pilot
ORDERING REPLACEMENT PARTS
COMMON ABBREVIATIONS
IMPORTANT BUILDING NOTES
4
To convert inches to millimeters, multiply inches by 25.4
