To order replacement parts for the Great Planes Ryan STA-M ARF, use the order numbers in the Replacement Parts List
that follows. Replacement parts are available only as listed. Not all parts are available separately (an aileron cannot be
purchased separately, but is only available with the wing kit). Replacement parts are not available from Product Support,
but can be purchased from hobby shops or mail order/Internet order firms. Hardware items (screws, nuts, bolts) are also
available from these outlets. If you need assistance locating a dealer to purchase parts, visit www.greatplanes.com and
click on “Where to Buy.” If this kit is missing parts, contact Great Planes Product Support.
Replacement Parts List
Order Number Description How to Purchase
Missing pieces ................................................Contact Product Support
Instruction manual...........................................Contact Product Support
Full-size plans .................................................Not available
Kit parts listed below.......................................Hobby Supplier
GPMA2280 ...........Wing Kit (R&L wing panels, R&L ailerons, hinge strip, 3 pc. ply forward wing
joiner, ply aft wing joiner, (2) wing dowels, wing bolt plate.)
GPMA2281 ...........Fuselage Kit (Fuselage, forward and aft servo trays, (4) hardwood cowl
mounting blocks, (2) cockpit coaming, (2) 1/4" x 3/8" x 6-3/8" [7 x 10 x
165mm] hardwood forward servo mount rails, 1/4" x 1/2" x 6" [6 x 13 x
150mm] balsa rudder pushrod tube support, (2) hardwood wing strut
mounting blocks.)
GPMA2282 ...........Tail Set (Fin & rudder, stab & elevators, hinge strip.)
GPMA2283 ...........Cowl (Fiberglass cowl, plywood cowl ring, (4) ply cowl discs.)
GPMA2284 ...........Windscreen Set (2)
GPMA2205 ...........Main Landing Gear Set (L&R)
GPMA2286 ...........Wheel Pants (L&R)
GPMA2287 ...........Wing Strut Set (2)
GPMA2288 ...........Axle Set ((2) axles, (4) wheel collars, screws, wrenches)
GPMA2289 ...........Rudder Pull-Pull Set (Braided rudder cable, (4) threaded brass couplers,
(4) metal clevises, (4) 2mm nuts, (4) copper swages.)
GPMA2290 ...........Decal Sheet Set (2 sheets)
GPMA2291 ...........Plastic Parts Set (Turtledeck, stab & fin fairings, R&L rudder fairing.)
GPMA2292 ...........Tailgear Set w/Wheel
ORDERING REPLACEMENT PARTS
0" 1" 2" 3" 4" 5" 6" 7"
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180
Inch Scale
Metric Scale
To convert inches to millimeters, multiply inches by 25.4
