ADDITIONAL ITEMS REQUIRED
Adhesives and Building Supplies
Foam safe CA glue and 30-minute epoxy are used in the
assembly of the L-39 ARF. Order numbers are provided below.
❏
Great Planes Pro ™ Epoxy 30-Minute Formula 4 oz.
(GPMR6043)
❏
Great Planes Pro Foam Safe CA- Thick Glue 1 oz.
(GPMR6072)
❏
Denatured alcohol (for epoxy clean up)
This manual also refers to using a 1/16" [1.6 mm] drill bit:
❏
Hobbico ® Pin Vise 1/16 Collet w/6 Bits (HCAR0696)
Optional Supplies and Tools
Here is a list of items that will help you build the L-39 ARF.
❏
CA debonder (GPMR6039)
❏
Epoxy brushes (6, GPMR8060)
❏
Mixing sticks (50, GPMR8055)
❏
Mixing cups (GPMR8056)
❏
CG Machine ™ (GPMR2400)
❏
Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
IMPORTANT BUILDING NOTES
• When you see the term test fi t in the instructions, it means
that you should fi rst position the part on the assembly
without using any glue, then slightly modify or custom fi t
the part as necessary for the best fi t.
• Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the
instructions will make a recommendation.
• Whenever just epoxy is specifi ed you may use either
30-minute (or 45-minute) epoxy or 6-minute epoxy. When
30-minute epoxy is specifi ed it is highly recommended that
you use only 30-minute (or 45-minute) epoxy, because you
will need the working time and/or the additional strength.
• Photos and sketches are placed before the step they
refer to. Frequently you can study photos in following steps
to get another view of the same parts.
ORDERING REPLACEMENT PARTS
Replacement parts for the L-39 ARF are available using the
order numbers in the Replacement Parts List that follows. The
fastest, most economical service can be provided by your
hobby dealer or mail-order company.
To locate a hobby dealer, visit the Great Planes web site
at www.greatplanes.com. Choose “Where to Buy” at the
bottom of the menu on the left side of the page. Follow the
instructions provided on the page to locate a U.S., Canadian
or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa
® or MasterCard ®
number and expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason, contact
Product Support by telephone at (217) 398-8970, or by
e-mail at [email protected].
Replacement Parts List
Order Number Description How to Purchase
Missing pieces ............... Contact Product Support
Instruction manual .......... Contact Product Support
Full-size plans ................................... Not available
Contact your hobby supplier for the following parts:
GPMA2772 ........... Wing Set with Tip Tanks
GPMA2773 ........... Fuse Kit with Hatch
GPMA2774 ........... Tail Set
GPMA2775 ........... Canopy Hatch
GPMA2776 ........... Armament Set
GPMA2777 ........... Display Stand
GPMA2778 ........... Tip Tanks (2)
GPMA2779 ........... Decal Sheet
GPMA3124 ........... Motor Lead Extension
GPMG3900 ........... HyperFlow Ducted Fan Unit
GPMG3940 ........... Ducted Fan Rotor Blade
GPMG3941 ........... Ducted Fan Miscellaneous Parts
GPMG3942 ........... Ducted Fan Outer Duct
GPMG3943 ........... Ducted Fan Adapter
