4. You must properly install the R/C radio system and other
components so that the model operates properly on the
ground and in the air.
5. You must test the operation of the model before every
flight to insure that all equipment is operating and you must
make certain that the model has remained structurally
sound. Be sure to check clevises or other connectors often
and replace them if they show signs of wear or fatigue.
Remember: Take your time and follow directions to end
up with a well-built model that is straight and true.
Please inspect all parts carefully before starting to build!
If any parts are missing, broken or defective, or if you
have any questions about building or flying this
airplane, please call us at (217) 398-8970. If you are
calling for replacement parts, please reference the part
numbers and the kit identification number (stamped on
the end of the carton) and have them ready when calling.
We can also be reached by E-Mail at:
[email protected]
Items in parentheses (GPMQ4243) are suggested part
numbers recognized by distributors and hobby shops and
are listed for your ordering convenience. GPM is the Great
Planes brand, TOP is the Top Flite
® brand, and HCA is the
Hobbico ® brand.
❏
Four-Channel Radio W/Five Servos
❏
“Y” Harness For Aileron Servos
❏
Engine – See Engine Selection
❏
Spare Glow Plugs (O.S. #8 For Most 2-Stroke
Engines, OSMG2691)
❏
Propeller (Top Flite ® Power Point ™ –Refer To Your
Engine’s Instructions For Proper Size)
❏
3' Medium 3/32" Fuel Tubing (GPMQ4131)
❏
1/4" Latex Foam Rubber Padding (HCAQ1000)
❏
Fueling System (Great Planes Top Fueler, GPMQ4160)
❏
(2) Flexible Cable Pushrod (GPMQ3702)
❏
1/5 Scale Pilot (Williams Bros. Sportsman Pilot,
WBRQ2485)
These are the building tools that are required. We
recommend Great Planes Pro
™ CA and Epoxy glue.
❏
2 oz. Pro CA (Thin, GPMR6003)
❏
2 oz. Pro CA+ (Medium, GPMR6009)
❏
CA Accelerator (GPMR6035)
❏
30-Minute Pro Epoxy (GPMR6047)
❏
1/4" Red Striping Tape(GPMQ1330)
❏
#1 Hobby Knife Handle (HCAR0105)
❏
#11 Blades (HCAR0311, 100 Qty)
❏
Builders Triangle Set (HCAR0480)
❏
Masking Tape (TOPR8018)
❏
Electric Power Drill
❏
Slip-Joint & Needle Nose Pliers
❏
Monofilament String For Stabilizer Alignment
❏
Screwdrivers (Flat Blade & Phillips)
❏
Pro Thread Locking Compound (GPMR6060)
❏
Isopropyl Alcohol (70%)
❏
Drill Bits: 1/16", 5/64", 3/32", 7/64", 1/8", 3/16", 11/64",
15/64", 1/4"
❏
Top Flite Trim Seal Tool ™ (TOPR2200)
❏
Felt-Tip Pen
❏
Sandpaper: 80, 220 & 320-grit
❏
Metal File
❏
6-Minute Pro Epoxy (GPMR6045)
❏
CA Applicator Tips (HCAR3780)
❏
Canopy Glue (JOZR5007)
❏
Epoxy Brushes (GPMR8060)
❏
Epoxy Mixing Sticks (GPMR8055, Qty. 50)
❏
CA Debonder (GPMR6039)
❏
Trim Seal Tool (TOPR2200)
❏
Dremel ® Moto-Tool ™ Or Similar W/Cut-Off Wheel
❏
Hot Sock ™ (TOPR2175)
❏
Dead Center ™ Engine Mount Hole Locator (GPMR8130)
❏
3/32" Brass Tube
❏
Curved Tip Canopy Scissors For Canopy
Trimming (HCAR0667)
❏
LustreKote ™ Paint For Aluminum Landing Gear
(White Primer TOPR7801, Missile Red TOPR7201)
❏
Switch and Charge Jack (GPMM1000)
Optional Supplies and Tools
Building Supplies and Tools
Required Accessories
PREPARATIONS
Engine Selection
There are several engines that will work well in your
Extra 300 ARF. We recommend a hot 2-stroke such as an
O.S.
® .46FX or SuperTigre ™ G45. If you prefer a 4-stroke,
an O.S. FS-70 is the ticket. Your choice of 2-stroke or
4-stroke will determine the location of the throttle servo
and throttle pushrod exit on the firewall, so plan ahead.
DECISIONS YOU MUST MAKE
Note: We, as the kit manufacturer, provide you with a
top quality kit and great instructions, but ultimately the
quality of your finished model depends on how you build
it; therefore, we cannot in any way guarantee
the performance of your completed model, and no
representations are expressed or implied as to the
performance or safety of your completed model.
3
