KIT CONTENTS

1. Cowl
2. Fuselage
3. Spinner
4. Fuel Tank
5. Engine Mount

6. Main Landing Gear
7. Main Wheels and Axles
8. Wheel Pants
9. Pushrods

10. Hinges/Hardware

11. Horizontal Stabilizer
12. Tail Wheel Assembly
13. Vertical Fin
14. Wing Halves
15. Wing Tube

1

10

12

14

14

13

15

11

2

4

6

8

3

5

7

9

Order No.

Description

NOTE

Full-size plans are not available.
You can download a copy of this
manual at www.greatplanes.com.

GPMA4230
GPMA4231
GPMA4232
GPMA4233
GPMA4234
GPMA4235
GPMA4236
GPMA4237
GPMA4238
GPMA4239

Wing
Fuselage
Tail Surface Set
Hatch
Cowl
Landing Gear
Wheel Pants
Spinner
Wing Tube
Decals

REPLACEMENT PARTS LIST

KIT INSPECTION

Before starting to build, take an inventory of this kit to make
sure it is complete, and inspect the parts to make sure
they are of acceptable quality. If any parts are missing or
are not of acceptable quality, or if you need assistance
with assembly, contact Product Support. When reporting
defective or missing parts, use the part names exactly as
they are written in the Kit Contents list.

Great Planes Product Support:

3002 N Apollo Drive, Suite 1

Champaign, IL 61822

Telephone: (217) 398-8970, ext. 5

Fax: (217) 398-7721

E-mail: [email protected]
