5. Mount the two 5/32 axles with the two axle nuts to the
main gear.
❏
6. Mount the main wheels to the axles with the 5/32"
[4mm] wheel collars. Using a Moto-Tool ® and cut-off wheel,
cut the axles off flush with the wheel collar.
❏
1. Cut away the covering where the pushrod tubes exit
the right side and top of the fuselage. Screw the nylon
clevises 20 turns onto the 36" pushrods. Place a silicone
retainer over each of the clevises. Holding the clevis end,
slide the two pushrods into the fuse through the openings
you just trimmed.
❏
2. Use the pushrods to set the location for the control
horns. Hold the horn in position and mark the location of the
mounting holes. Drill 3/32" [2.4mm] mounting holes through
the marks. Attach the horns using #2 x 1/2" [13mm] screws
and nylon nut plates. Do not over-tighten the screws, as this
may crush the underlying balsa. Attach the clevis to the
control horns using the second hole in from the outside and
slip the silicone retainer into place on the clevis.
Correct Incorrect
RADIO INSTALLATION
13
