BX SERIES HANDHELD INSTRUCTION MANUAL PAGE 13
Transmitter
BX710 RF Output: High- 5 Watts Max.
Low- 1 Watt.
BX720/730 RF Output: High- 4 Watts Max.
Low- 1 Watt.
Spurious Emissions: < -26 dBm
Frequency Stability: 25 kHz: ± 3 kHz
12.5 kHz: ±1.5 kHz.
Modulation: FM
Maximum Deviation: 25 kHz < ±5 kHz
12.5 kHz < ±2.5 kHz
Transmit Frequency
Response: + 6 dB per octave 300 Hz to 3 kHz, +1, -3 dB.
Current Consumption
(Max.): 1.7 Amps @ 4 Watts
0.7 Amps @ 0.75 Watts
Receiver
Intermediate Frequencies: 1st: 45.3 MHz
2nd: 455 kHz.
Sensitivity: -119 dBm for 12 dB SINAD
Adjacent Channel
Selectivity: 25 kHz > 63 dB
12.5 kHz > 60 dB
Intermodulation: 25 kHz > 60 dB
12.5 kHz > 60 dB.
Blocking: 25 kHz > 80 dB
12.5 kHz > 80 dB.
Spurious Rejection: 25 kHz > 60 dB
12.5 kHz > 60 dB.
Audio Output Power: 0.6 Watts @ < 10% distortion
Receiver Frequency
Response: - 6 dB per octave de-emphasis
Current Consumption: 25 mA: Sleep Mode
65 mA: Muted
250 mA: Full volume
MEChANICAL SPECIFICATIONS
Dimensions: 62 (W) x 98 (H) x 30 (D) mm Measured without antenna.
ENVIRONMENTAL
Operating Temperature: -10°C to 60°C
*Specifications are typical unless otherwise indicated and may be subject to change
without notice or obligation.
