PA G E 1 8
I N S T R U C T I O N M A N UA L
T X 6 1 5 0 / T X 6 8 5
STANdARd COMMuNICATIONS
WARRANTY AGAINST dEFECTS
This warranty against defects is given by Standard Communications Pty Ltd ACN 000 346 814 (We,
us, our or GME). Our contact details are set out in clause 2.7. This warranty statement only applies to
products purchased in Australia. Please contact your local GME distributor for products sold outside of
Australia. Local distributor details at www.gme.net.au/export.
1. Consumer guarantees
1.1 Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
1.2 To the extent we are able, we exclude all other conditions, warranties and obligations which would
otherwise be implied.
2. Warranty against defects
2.1 This warranty is in addition to and does not limit, exclude or restrict your rights under the
Competition and Consumer Act 2010 (Australia) or any other mandatory protection laws that
may apply.
2.2 We warrant our goods to be free from defects in materials and workmanship for the warranty period
(see warranty table) from the date of original sale (or another period we agree to in writing). Subject
to our obligations under clause 1.2, we will at our option, either repair or replace goods which we
are satisfied are defective. We warrant any replacement parts for the remainder of the period of
warranty for the goods into which they are incorporated.
SpECIFICATIONS
General
Frequency Range: 476.425 - 477.4125 MHz
Channel Spacing: 12.5 kHz
No of Channels: 80, (75 voice, 2 telemetry RX only, 3 for future use).
CTCSS Codes: 50
DCS Codes: 104
Dimensions (W x H x D): 57 mm x 102 mm x 35 mm (without antenna)
Complies with: AS/NZS 4365: 2011
Power supply
Power Source: Li-Ion rechargeable - 7.4V DC, 2200 mAh (TX6150)
2000 mAh (TX685)
Operating Time: 10 Hours (High Power)
(Transmit 5%, Receive 5%, Standby 90%)
Receiver
Usable Sensitivity: -121 dBm
Maximum Audio Output: >0.5 watt max. (8 Ohm)
Modulation Distortion: <5% (1 kHz 70%)
Transmitter
Transmit Power: Hi 5 watts (TX6150)
3 watts (TX685)
Lo 1 watt
NoTe:
Specifications are typical unless otherwise indicated and may be subject to change without notice
or obligation.
