PAGE 10 INSTRUCTION MANUAL TX2720
ELECTRICAL
General
Complies With: AS/NZS4355:2006
Frequency Range: 26-30 MHz
Channel Set: Australian 27 MHz
CB (26.965 – 27.405 MHz)
Modulation: AM (A3E)
Supply Voltage: • 12 V DC nominal
• 10.8 – 15.6 V DC range.
Frequency Error: ±1.4 KHz
Dual Watch: Monitor time – 250 ms
Scan Rate: 5 channels/second
Transmitter
Modulation
Frequency
Response: 300 Hz to 3 kHz, +1 – 3 dB
Max Modulation
Depth: 100%
Carrier Output
Power: 4 watts max
Spurious Emissions: < -26 dBm
Receiver
Demodulated
Frequency
Response: 300 Hz to 3 kHz, +1 – 3 dB
Receive Sensitivity
for 12 dB SINAD @
30% Modulation: -110 dBm
Max Squelch: < -65 dBm
Adjacent Channel
Sensitivity: ≥ 55 dB
Spurious Response
Immunity: ≥ 55 dB
Conducted
Spurious
Radiation: ≤ -57 dBm
Audio Output
Power 8 Ohms: 2.5 watts
MECHANICAL
Dimensions (mm): 51 (H) x 94 (D) x 170 (W)
Weight: 450 grams
ENVIRONMENTAL
Temperature
Range: -0°C to + 55°C
The TX2720 will operate over the 26-30 MHz
frequency range. For information specific to
frequencies outside of the Australian CB bands,
please refer to the appropriate amendment, or
contact GME at: [email protected]
SPECIFICATIONS
Specifications are typical unless otherwise indicated and may be subject to change
without notice or obligation.
NOISE SUPPRESSION
27 MHz CB radio can be prone to electrical and
ignition interference. The reason is that electrical
noise is a form of AM transmission similar to that
used by your radio and your radio’s receiver is
very sensitive. In most cases, ignition noise can
be greatly reduced or eliminated by selecting
the Noise Limiter (NL) key on the radio. In some
severe cases additional suppression may need to
be fitted to the ignition system of your vehicle in
which case we recommend you consult an auto
electrician for advice specific to your installation.
