R C 9 0 0 B T I N S T R U C T I O N M A N UA L PA G E 7
Reset Button
When the installation is complete, press the Reset
button using a paper clip or similar object (see
PRECAUTIONS on page 4). This will ensure the
RC900BT is ready to operate for the first time. If at
any time the controls do not seem to work (after
replacing the vehicle’s battery for example), press
the Reset button to reset the microcomputer inside
the RC900BT.
Fuse Replacement
If any of the fuses blow, replace them with a
standard 30 mm 3 AG type of the same rating. If the
fuse blows a second time contact your retailer.
The following fuse ratings are used:
- Yellow ‘Memory’ lead: 15 amp.
- Red ‘Ignition Switch ACC’ lead: 0.5 amp.
OPERATION
GENERAL FUNCTIONS
1 Power ON/OFF
To turn the RC900BT ON, press the Power Button.
The unit will resume the mode and settings that
were selected when last turned OFF.
To turn the RC900BT OFF, press the Power button
again. Note that when the RC900BT is turned OFF
the clock is displayed without the backlight.
Backlighting
Briefly press the Power button to change the
brightness of the back lighting. There are three
levels of backlighting available.
2 3 Audio Controls (VOL, SEL)
The Volume, Bass, Treble, Balance and Fader
controls are selected electronically. The default
setting is the Volume control.
To select an alternative control, press the SEL 3
button until the desired function is displayed on
the LCD. Each press cycles to the next function in
sequence. Adjust the selected control function using
the Volume control
2 .
4 Loudness
Pressing the LOU button will provide a low
frequency (bass lift) boost to the audio output. To
indicate the selection ‘LOUD’ will be illuminated
on the LCD. Pressing the LOU button again will
de-select the loudness function.
5 Mute
Pressing the MUT button will temporarily silence the
audio output. ‘MUTE ON’ is displayed on the LCD
to indicate the RC900BT has been muted. Pressing
the MUT button again will restore the previously
selected audio level.
6 Clock/Time Selector
To toggle the current time on or off, press the
button.
The time is shown in the 24 hour format.
To set the clock, press and hold the button until
the time display begins to flash. The time can then
be adjusted by rotating the Volume control. To
adjust hours, rotate the control clockwise, to adjust
the minutes, rotate anti-clockwise.
7 Mode Switch
Pressing the MOD button will select the RC900BT
operating mode. TUNER, CD or AUX modes are
sequentially selected as MOD is pressed. If a USB
memory stick or SD Card is inserted, ‘USB’ or ‘CARD’
will also appear in the mode list. When the RC900BT
is switched ON it will automatically return to the
mode it was in when switched OFF.
8 Local/Distance Control
Pressing the LOC button selects an internal
attenuator which will help to reduce the interference
and distortion often associated with very strong
local radio transmissions. For long distance reception
select the DX option. Local or DX is displayed
momentarily when the LOC button is pressed.
9 Stereo/Mono Selector
Pressing the ST button selects either mono or
stereo reception while in FM mode. The unit will
momentarily display ‘MONO’ or ‘STEREO’ when
toggling the ST switch. The ST flag is displayed
when the RC900BT is in the stereo mode.
Selecting MONO improves reception when FM
signals are weak or noisy by disabling stereo
detection.
Select STEREO for normal listening on FM radio
bands, a
symbol is displayed when stereo
signals are being received.
